Our Laboratories
PoliMill
Spindle
Speed
200 to 40’000 rpm
Power
5 kW (S1 = 100%ED) @ 27’000 rpm
7.5 kW (S3 = 25%ED per 10 min) @ 27’000 rpm
Torque
1.8 Nm (S1 = 100%ED) @ 27’000 rpm
2.7 Nm (S3 = 25%ED per 10 min) @ 27’000 rpm
Spindle Interface
HSK-E32 (DIN 69893-5)
ATC
Dimensions
90 positions HSK-E32
Linear Axis
Rapid Feedrate
20’000 mm/min, feedrate
Feedrate
12’000 mm/min
Axis Stroke
Transversal X 630 mm
Longitudinal Y 490 mm
Vertical Z 280 mm
YASDA YMC650+RT20
YMC 650+RT20 is a cutting-edge machine that allows a wide range of 5-axis machining with high precision and surface quality. The high precision is achieved thanks to linear motors with guides with resolution in the order of a hundredth of a micron and thanks to a thermal stabilization system.
Maximum blank dimensions
Ø 330 X H 242
Maximum Blank Weight
35kg with pallet
Blocking Surface (Zero-Point)
Erowa Ø148 mm
Resolution
0.00001 mm & 0.00001°
Control
FANUC 31i-B5
Internal Lubrication
0.6 MPa
Tilt/Continuous Rotation
Rapid Feedrate
100 rpm
Tilt
B: -10° to 100°
Rotation
C: 0° at 360°
Software
The software that is most used in the PoliMill laboratory are: VERICUT, Siemens NX, Autodesk Inventor Professional, SolidWorks, KeyShot Pro, Camtasia, Adobe Illustrator and Adobe InDesign.
MI_croLab
Control
Heidenhain iTNC 530
Linear Axis
Blocking System
max. 350 x 230 mm
Workpiece weight
35 kg
Feedrate
0.01 – 16 m/min
Acceleration
8 m/s²
Axis Stroke
Transversal X 300 mm
Longitudinal Y 280 mm
Vertical Z 250 mm
KERN Evo
Thanks to its structure and high acceleration and feed values, it is possible to achieve excellent surface finishes. The short distances between the part and the drives reduce angular error to a minimum and guarantee maximum accuracy and repeatability of positioning
Spindle
Speed
50’000 rpm
Power
6.4 kW
Torque
1.5 Nm
Precision according to VDI/DGQ 3441
Resolution
0.1 µm
Positioning tolerance
P ± 1.0 µm
Positioning dispersion
PS ± 0.5 µm
Precision on workpiece
± 2.0 µm
WJ_Lab
High-Pressure Intensification
BHDT Ecotron 4037
Power
37 kW
Maximum water pressure
380 MPa
Maximum water flow
3.5 l/min
Campo di lavoro
Trasversale X 3210 mm
Longitudinale Y 2080 mm
Verticale Z 200 mm
Abrasive
Garnet #80
Intermac Primus 322 Metal
The ease of use and the ability to cut all materials, combined with high quality, precision and cutting finish, make the Primus range suitable for a wide range of users.
Primus offers the possibility of processing a wide range of materials ferrous and non-ferrous, non-metallic alloys, titanium, aluminium, plastic and composite materials.
Handling system
Gantry architecture
Sistema di movimentazione delle teste di taglio a 5 assi
Tilt, A°
continuous tilting, +60°/-60°
Rotary, C°
continuous rotation, infinite
Cutting head
primary orifice
Ø 0,33 mm
Focuser
Ø 1,02 mm
